Gel instrument is a technique used in laboratory to separate charged molecules like DNA, RNA and proteins according to their size. Gel electrophoresis instruments are commonly used to run and compare DNA samples.
Key Features
- The zoom, focus, aperture, UV light and white light can be controlled by PC.
- Auto-delay-shutdown function for UV light.
- 6x zoom lens, easy to observe the zooming of gel.
- The zoom, focus, aperture, UV light and white light can be controlled by PC.
Application
Forensic, molecular biology, genetics, microbiology labs, gel electrophoresis instruments
Technical Specifications
Detailed operating and construction parameters for this model.
| Model | BGEL-501 |
| Effective pixel | 1280×1024 |
| Pixel density | 10 bit |
| Pixel size | 5.4×5.4 (μm) |
| Resolution | 1.4 megapixels |
| Signal to noise ratio | ≥56 db |
| Sensitivity | Can detect the double chain DNA of EB staining below 20 pg |
| Camera | Low illumination and high resolution digital CCD |
| Zoom lens | F=1:1.2, 2/3 inch 6x zoom lens |
| Filter | 590 (nm) |
| UV light transmission size (WxL) | 250×200 mm |
| Visible light transmission size (WxL) | 250×210 mm |
| Transmission UV wavelength | 302 nm |
| Reflectance UV wavelength | 254, 365 nm |
| Transmission UV lamp power | 302 nm (8W) |
| Reflectance UV lamp power | 254 nm (11W), 365 nm (11W) |
| Dimension (LxWxH) | 470x405x820 mm |
| Weight | 29.0 kg |
| Model | BGEL-501 |
| Effective pixel | 1280×1024 |
| Pixel density | 10 bit |
| Pixel size | 5.4×5.4 (μm) |
| Resolution | 1.4 megapixels |
| Signal to noise ratio | ≥56 db |
| Sensitivity | Can detect the double chain DNA of EB staining below 20 pg |
| Camera | Low illumination and high resolution digital CCD |
| Zoom lens | F=1:1.2, 2/3 inch 6x zoom lens |
| Filter | 590 (nm) |
| UV light transmission size (WxL) | 250×200 mm |
| Reflectance UV wavelength | 254, 365 nm |
| Transmission UV lamp power | 302 nm (8W) |
| Reflectance UV lamp power | 254 nm (11W), 365 nm (11W) |
| Dimension (LxWxH) | 470x405x820 mm |
| Weight | 29.0 kg |
Images are reference only. Actual product may be different.
