- Product Features
High accurate and flexible identification of a wide range of the unknown substance with extensible substance library - High speed inspection
- no warm up time. It can directly detect once turn on
- Handheld and ergonomic design
- Non-destructive and Non-radioactive testing
- Analyze and identify substances in several seconds typically
- Micro USB2.0 and Wi-Fi for data transfer and software update
- Can check the information from mobile phone software
- Integrated Bluetooth for data sending
- Friendly operation based on touch-screen with graphical user interface and minimal training required Virtual keyboard: Built-in Win8.1 system, a virtual keyboard operation, easy to input.
Application
Widely used in Pharmaceutical chemical, Army/Police/Anti-terrorism, subway, railway, public security, border police, government Units, postal logistics, other key security zone, the human body clothing, luggage, drugs left on the surface of the goods, explosives, other prohibited items, suspicious objects can be quickly detected.
Technical Specifications
Detailed operating and construction parameters for this model.
| Model | BDRD-301 |
| Explosives | TNT, RDX, PETN, Octagon, Sulfur and Ammonium Nitrate, etc. |
| Narcotics |
Cocaine hydrochloride, Palavering hydrochloride, Methamphetamine (meth), Methamphetamine and Ketamine hydrochloride (K), etc. |
| Liquid Threats |
Acetic acid, Acetic anhydride, Ethanol, Chloroform, Methanol, Toluene, Acetone, Pyridine, Benzene, Ethyl ether, Cyclohexane, 1-2 Dichloroethane, Xylene, N,N-dimethylformamide, Isoamyl alcohol, Isopropyl alcohol, Nitrobenzene, Cyclohexanone, Isoamyl acetate, Tetrahydrofuran, etc. |
| Others | Infinitely extension database |
| Spectrum range | 200-3900 cm-1 |
| Resolution | 8-10 cm-1 |
| Laser wavelength | 785 nm |
| Laser security classification | 3 B |
| Detector | Backside highly-sensitive CCD detector |
| Laser consumption | 0-500mW adjustment |
| Integral Time | 100 ms – 5 s |
| Analysis Time | 3 s |
| Alarm | Audio and visual alarm. And show you test result |
| Detection Way | Acquiring a usable signal a few millimeters away from the sample |
| Probe working focal length | 8 mm |
| Warm up time | No |
| Working temperature | 0°C to 40°C |
| Working humidity | ≤93% |
| Storage temperature | -20°C to 55°C |
| Storage humidity | ≤80% |
| Data | By USB or wireless to import or export |
| Data storage | Save 300,000 records |
| Battery | Rechargeable 4 hours lithium battery |
| Dimension (LxWxH) | 160x222x74 mm |
| Weight | 2.3 kg |
| Power | 12V/3A adaptor |
Images are reference only. Actual product may be different.
