Chromatography is a technique that enables the separation, identification, and purification of the components of a mixture for qualitative and quantitative analysis. Our extensive range offers a variety of products like Gas, Ion and Portable Ion chromatography products to meet all separation needs, including improved resolution, enhanced sensitivity, faster analysis and consistent performance.
Product Features
- Built-in circulating 3D constant temperature technology:
- Temperature stability time is less than 30 mins, ensuring the accuracy and
- reliability of test data.
- The world’s leading full-range series of ion chromatographic columns:
- High efficiency, large capacity of the columns for detecting ions of varied
- compositions.
- Self-Regenerating Electrolytic Micro-membrane Suppressor:
- High pressure resistance, small dead volume, highly responsive to signals.
- Auto-range Conductivity Detector:
- It can directly detect the signal from ppb to ppm without adjusting the range. Only one conductivity detector can detect anions and cations.
- Observatory intelligent workstation:
- Integrated control, intelligent start-up, shutdown and maintenance functions. Compatible with a variety of instruments.
Application
Food Testing, Chemical Industry, Beverage Testing, Drug testing, Forensic Science, Pharmaceutical, Molecular Biology, Medical, Research, Laboratory.
Technical Specifications
Detailed operating and construction parameters for this model.
| Model | BCHR-101 |
| Ion Chromatographic Pump | |
| – Maximum Pressure | 42 MPa (Stainless steel) |
| – Type | High-pressure and low-pulse two-piston tandem advection pump |
| – Pressure Display Accuracy | ≤ 0.1 MPa |
| – Flow Range | 0.001 ~ 9.999 mL/min |
| – Pressure Fluctuation | ≤ 0.5% |
| – Flow Stability | (0.2-0.5) mL/min ≤ 2%; (0.5-1.0) mL/min ≤ 1%; >1.0 mL/min ≤ 1% |
| Manual Sample Injector | |
| – Contact Material of the Rotor | PEEK |
| – Contact Material of Medium | PEEK/Ceramics |
| Column Heater | |
| – Operating Temperature Range | 20°C~60°C (68~140°F) |
| – Controlling Temperature Accuracy | ±0.01°C |
| – Allowable Deviation of Column Heater’s Temperature | ±1°C |
| – Temperature Stability | ≤0.05°C/h |
| Conduction Detection System | |
| – Type | Constant temperature auto-range conductivity detector |
| – Cell Volume | ≤0.8μL |
| – Detection Range | 0~35000 μS/cm |
| – Detection Resolution | ≤0.0020nS/cm |
| – Output Voltage | -6000~+6000 mV (adjustable) |
| – Electronic Noise | 0.02 nS |
| – Baseline Noise | ≤0.001 μS/cm |
| – Baseline Drift | ≤0.02μS |
| – Operating Temperature Range | Room temperature +5°C~60°C (41~140°F) |
| – Controlling Temperature Accuracy | ±0.01°C |
| – Temperature Compensation | 1.7%/°C |
| – Maximum Pressure | 10.0 MPa |
| – Linear Range | ≥10³ |
| – Instrument Linearity | ≥0.999 |
| – Quantitative Repeatability | ≤1.0% |
| Qualitative Repeatability | ≤0.5% |
| Minimum Detectable Concentration | Cl⁻ ≤0.0005 μg/mL; Li+ ≤0.001 μg/mL; BrO₃⁻ ≤0.001 μg/mL |
| Flow System | |
| – Six-way Valve | PEEK material, pressure 5000 psi; Independent automatic collecting and flow function. |
| Suppressor | |
| – Type | Self-Regenerating electrolytic micro-membrane suppressor |
| – Maximum Pressure | 6.0 MPa |
| – Dead Volume | <50 μL |
| Other Specifications | |
| – Dimension (LxWxH) | 350x470x510 mm |
| – Net Weight | 26 kg |
| – Gross Weight | 32 kg |
| – Power | 150 W |
Images are reference only. Actual product may be different.
